Infrared thermometerDescription
Medical diagnostic device in vitro CE 0482.
The non-contact infrared thermometer measures the temperature of the human body or objects based on infrared energy emanated by the front or from an object (eg milk or water). Rapid measurement results can be obtained after pointing the temperature meter on the object.
The infrared temperature sensor collects infrared energy emitted by the front. After being captured via a lens, the energy is converted into temperature from thermopyls and the measurement circuit.
Carefully read the warnings and instructions for use.
Specific
Power mode: Internal power supply.
Operating voltage: DC 3V.
Battery model: AAA x 2.
Battery duration: Alkaline dry batteries for about 20,000 measurements.
Operation mode: Continuous operation.
Power consumption: <60 MW.
Display: LCD to segments.
Duration of each measurement: about 1 second.
Emissivity: 0.95.
Measurement distance: 1-5 cm.
Memory: 20 temperature readings.
External dimensions: 160x56x46 mm.
Weight: 97.4 g (with batteries).
Waterproof level: IPX0.
How to use
1. Select the temperature mode: front or object.
2. Keep the measurement probe a few inches from the person or from the object.
3. Press the measurement button.
4. After issuing a beep, the detected temperature will appear on the display.
5. Holding down the measurement button, continuous measurements will be read and the highest temperature will be recorded.
Precautions
- Do not use the thermometer for continuous temperature monitoring purposes.
- Do not put the thermometer in water or other liquid, it is not water repellent.
- Clean and disinfect the thermometer as described in the manual.
- Do not touch the tip of the temperature meter on which a precision temperature sensor is placed.
- The room temperature must not be too high or low. To ensure accurate reading, keep the thermometer at room temperature for more than 30 minutes before use.
- Do not use the thermometer with room temperature greater than 40 ° C (104 ° F) or less than 10 ° C (50 ° F), which are beyond the thermometer operating temperature range.
Warnings
- The thermometer is not intended for the diagnosis or treatment of any disorder or disorder. Measurement results are only to be taken as a reference.
- It is dangerous to perform self-diagnosis or treatments based on the results of the measurements obtained. To these purposes, please consult a doctor or other health professionals.
- Do not recharge a dry alkaline battery or throw it into the fire. Otherwise the battery could explode.
- Do not disassemble the thermometer in an attempt to repair it. Otherwise the thermometer could be permanently damaged.
- During measurement, do not use mobile phones or other devices that can cause electromagnetic interference.
- Do not use the thermometer in an environment in which flammable aesthetic compounds based on air, oxygen or nitrogen protractor.
Storage
The thermometer must be packed and stored in a well-ventilated room in the absence of corrosive gases. The room temperature must be between -10 ° C and + 50 ° C (14 ° F-122 ° F), the relative humidity must be less than 93% (without condensation), and atmospheric pressure 50-106 kPa.
The duration of the thermometer is 5 years.
Format
Box containing 1 piece.
Medical diagnostic device in vitro CE 0482.
The non-contact infrared thermometer measures the temperature of the human body or objects based on infrared energy emanated by the front or from an object (eg milk or water). Rapid measurement results can be obtained after pointing the temperature meter on the object.
The infrared temperature sensor collects infrared energy emitted by the front. After being captured via a lens, the energy is converted into temperature from thermopyls and the measurement circuit.
Carefully read the warnings and instructions for use.
Specific
Power mode: Internal power supply.
Operating voltage: DC 3V.
Battery model: AAA x 2.
Battery duration: Alkaline dry batteries for about 20,000 measurements.
Operation mode: Continuous operation.
Power consumption: <60 MW.
Display: LCD to segments.
Duration of each measurement: about 1 second.
Emissivity: 0.95.
Measurement distance: 1-5 cm.
Memory: 20 temperature readings.
External dimensions: 160x56x46 mm.
Weight: 97.4 g (with batteries).
Waterproof level: IPX0.
How to use
1. Select the temperature mode: front or object.
2. Keep the measurement probe a few inches from the person or from the object.
3. Press the measurement button.
4. After issuing a beep, the detected temperature will appear on the display.
5. Holding down the measurement button, continuous measurements will be read and the highest temperature will be recorded.
Precautions
- Do not use the thermometer for continuous temperature monitoring purposes.
- Do not put the thermometer in water or other liquid, it is not water repellent.
- Clean and disinfect the thermometer as described in the manual.
- Do not touch the tip of the temperature meter on which a precision temperature sensor is placed.
- The room temperature must not be too high or low. To ensure accurate reading, keep the thermometer at room temperature for more than 30 minutes before use.
- Do not use the thermometer with room temperature greater than 40 ° C (104 ° F) or less than 10 ° C (50 ° F), which are beyond the thermometer operating temperature range.
Warnings
- The thermometer is not intended for the diagnosis or treatment of any disorder or disorder. Measurement results are only to be taken as a reference.
- It is dangerous to perform self-diagnosis or treatments based on the results of the measurements obtained. To these purposes, please consult a doctor or other health professionals.
- Do not recharge a dry alkaline battery or throw it into the fire. Otherwise the battery could explode.
- Do not disassemble the thermometer in an attempt to repair it. Otherwise the thermometer could be permanently damaged.
- During measurement, do not use mobile phones or other devices that can cause electromagnetic interference.
- Do not use the thermometer in an environment in which flammable aesthetic compounds based on air, oxygen or nitrogen protractor.
Storage
The thermometer must be packed and stored in a well-ventilated room in the absence of corrosive gases. The room temperature must be between -10 ° C and + 50 ° C (14 ° F-122 ° F), the relative humidity must be less than 93% (without condensation), and atmospheric pressure 50-106 kPa.
The duration of the thermometer is 5 years.
Format
Box containing 1 piece.
