Descrizione Clinica
Thermometers - traditional thermometers - temperature devices Medel ear temp Medel
me
EAR TEMP
Description
The ear thermometer with infrared technology can detect body temperature in the ear canal of adults and children safely, quickly and not invasively. Includes 15 replaceable caps for hygienic and safe measurement. Detects the temperature in seconds with sound indicator at the end of the measurement.
Technical characteristics
Temperature measurement range:
- ear: 28°-43°C (82,4°-109,4°F)
- surface: -20°-100°C (-4°-212°F)
- environment: 0°-50°C (32°-122 °F).
Laboratory measuring accuracy:
- ear: ±0,2°C (0,4°F) in range 35,5°-42°C (95,9°-107,6°F); ± 0.3°C (0,5°F) in range ≤ 35,5°C (95,5°F) and ≥ 42°C (107,6°F)
- superficial: ± 4% or ± 2°C (4°F)
- environment: ± 2°C (± 4°F).
Clinical repeatability: 0.11°C (0.2°F).
Duration of measurement: about a second.
Operating temperature range: 10°-40°C (50-104°F), air humidity 15-85% (non-condensing).
Storage temperature range: -25°-55°C (-13°-131°F), air humidity 15-95% (non-condensing).
Memory: 10 memory positions.
Display resolution: 0.1°C or 0.1°F.
Batteries: CC 3 V (2 AAA batteries 1.5 V).
Ingombro: 155x38x47 mm.
Weight: about 63 g (battery excluded).
Protective caps: 10.
Automatic shutdown: 60 seconds.
Battery life: 3,000 consecutive measurements or one year with 1-2 measurements per day including standby mode.
Security classification: connected medical device type BF.
IP protection class: IP 22, protection against water and dust penetration.
Warnings
In case of ear measurements, carefully insert the thermometer sensor tip into the ear.
In the presence of certain acute and infectious diseases, the use of the thermometer per ear on several people, despite the cleanliness and disinfection, is not recommended due to the possible exchange of germs. For special cases, please contact your doctor.
The body temperature measured in the ear can differ from other measurements carried out in the mouth, in the rectum or under the armpits. It therefore makes no sense to compare these values. Regularly measure the temperature to calculate the normal ear temperature.
Then use such measurements as a basis of comparison with measurements performed in case of suspected fever.
This thermometer is intended for ear temperature measurements. Do not use it for measurements on other parts of the body.
Replace the protective cap after each use to ensure accurate measurement and avoid cross contamination.
The ear thermometer can be used exclusively with Medel protection caps, other caps can determine measurement errors. If the plugs are exhausted, please contact the manufacturer or specialist dealer to buy more.
Ask a doctor in case of precarious health conditions.
Prevent the device from impacting.
Do not expose the appliance to direct sunlight.
Avoid contacting liquids.
The thermometer is not waterproof.
Avoid any direct contact with water or other liquids.
Repair the appliance only from authorized service centers, otherwise the warranty expires.
High-frequency portable and mobile devices can affect the operation of the appliance. For more detailed information, please contact Customer Support or consult the end of the instructions for use.
Format
The package contains:
- 1 thermometer per ear
- 2 1.5 V AAA batteries
- 15 protective caps
- instructions for use.
Cod. 95132
